ITECH IT-N6333B Triple-Channel DC Power Supply CH1/2: (60 V/5A/200 W), CH3: (15 V/5 A/45 W), USB/LAN/Dig IO/RS232 Interface
Key Features and Functions
- 4.3-inch Color LCD Display
- Fully Isolated Triple Channels with Independent Control
- Multiple Output Modes: Series, Parallel, and Synchronous
- Auto Range Mode for Versatile Testing Needs
- Transient Response Time: ≤50 μs
- High Accuracy: ≤0.02% + 3 mV / ≤0.03% + 1.5 mA
- Programming Response Time: 5 ms
- Low Output Ripple and Noise
- CC/CV Priority Modes
- Comprehensive Protection Features: OVP, UVP, OCP, UCP, OPP, OTP, and FOLDBACK
- Supports Local and Remote Sensing Modes
- Built-in USB, LAN, Digital I/O, and RS232 Communication Interfaces (on Select Models)
Documents and Software Solutions:
The IT-N6300 Series is a high-performance triple-output DC power supply from ITECH, housed in a compact 2U half-rack chassis.
Each channel operates independently, with series/parallel and synchronization capabilities for versatile testing needs.
A 4.3-inch high-resolution LCD offers intuitive control for parameter setting, test programming, and waveform monitoring.
High-resolution output (1 mV/0.1 mA) ensures precise voltage and current delivery. With low ripple, CC/CV priority modes, and FOLDBACK protection, the IT-N6300 ensures stable and safe operation.
Flexible control options, including panel and remote programming, simplify system integration. Ideal for labs, manufacturing, and communications testing, the IT-N6300 combines precision, reliability, and efficiency for advanced power management.
The IT-N6300 Series is a high-performance triple-output DC power supply from ITECH, housed in a compact 2U half-rack chassis.
Each channel operates independently, with series/parallel and synchronization capabilities for versatile testing needs.
A 4.3-inch high-resolution LCD offers intuitive control for parameter setting, test programming, and waveform monitoring.
High-resolution output (1 mV/0.1 mA) ensures precise voltage and current delivery. With low ripple, CC/CV priority modes, and FOLDBACK protection, the IT-N6300 ensures stable and safe operation.
Flexible control options, including panel and remote programming, simplify system integration. Ideal for labs, manufacturing, and communications testing, the IT-N6300 combines precision, reliability, and efficiency for advanced power management.
