Keysight EDUX1EMBD Embedded Serial Triggering and Analysis (I2C, RS-232) for EDUX1000 series Oscilloscopes
For upgrade of existing EDUX1002A/G
The fastest throughput oscilloscope solution for triggering on and analyzing I²C and UART/RS-232 serial buses
- Support for the I²C serial protocol
- Support for the UART (RS-232) protocol
- On-screen serial decode time-correlated with the serial data waveforms
- Protocol trigger and hardware-based protocol decode
The I²C and UART/RS-232 serial decode option for InfiniiVision 1000 X-Series oscilloscopes displays responsive, time-aligned, on-screen decode of Inter-Integrated Circuit (I²C) and UART/RS-232 serial communication buses. Because this capability is hardware-based, it provides the fastest throughput solution for triggering on and analyzing these serial buses. These buses are found in a wide variety of embedded designs. This measurement application option works with InfiniiVision 1000 X-Series EDUX1002A and EDUX1002G models.
The I²C and UART/RS-232 serial decode option for InfiniiVision 1000 X-Series oscilloscopes displays responsive, time-aligned, on-screen decode of Inter-Integrated Circuit (I²C) and UART/RS-232 serial communication buses. Because this capability is hardware-based, it provides the fastest throughput solution for triggering on and analyzing these serial buses. These buses are found in a wide variety of embedded designs. This measurement application option works with InfiniiVision 1000 X-Series EDUX1002A and EDUX1002G models.
