ITECH FCS3000 Fuel Cell Simulation Software
FEATURES
- Automatic wide range output, voltage up to 2250V
- The power of the fuel cell simulator can be expanded to 1152kW
- User-defined FC polarization curve (4096 points can be edited)
- Support .csv file import
- Data storage and export
- Graphical software operation interface, real-time display the output voltage, current and power
Application
- Study the power performance and economic performance of FC propulsion systems
- Verify the input performance of the FC DC-DC module
- Study the parameter matching of the key components of the FC propulsion system
- Research on vehicle energy management strategies for FC propulsion systems
- Verify the control strategy of peak and valley adjustment in distributed energy applications
The FCS3000 fuel cell simulation software matched with IT6000C bidirectional DC power supply and IT6000B regenerative power system, can
accurately simulate the polarization characteristic curve of the fuel cell stack. The maximum voltage can reach 2250 V and the power can be
expanded to 1152 kW to meet the test requirement of high-power fuel cell simulation.
FCS3000 is designed to replace real fuel cell systems and provide an efficient simulation platform for research on hydrogen energy hybrid
propulsion systems. It can overcome the weakness of high cost, complex platform building and weakening of fuel cell performance in experiments
testing with real fuel cell stacks. FCS3000 has simple interfaces which is easy for configuration. At the same time, the complete data report also
provides important data support for theoretical research.
What is a fuel cell simulator?
The fuel cell simulator replaces the real fuel cell stack and complex devices such as hydrogen and oxygen device, and provides an easy operating
simulation platform for theoretical research. It also avoids the problems of high hydrogen cost and complex device building when using real fuel cells
for testing. It’s good for studying the energy distribution of the fuel cell propulsion system and evaluation of overall dynamic performance and
economic value.
FCS3000 with IT6000B/C DC power supply can provide a complete fuel cell simulation solution.
