ITECH IT8732P+ DC Load Module (150 V, 60 A, 400 W))
Modular load used with IT8702P mainframe
- Stable operation down to zero volts, suitable for low-voltage capacitors, solar cells, fuel cells, and other low-voltage high current power supplies
- Three-stage current range, higher accuracy and lower ripple
- Supports master-slave parallel connection of 16-channel modules
- Faster dynamic response, minimum current rise time < 10 μs
- Faster loop speed, precise control of current without overshoot
- The voltage and current measurement speed is upgraded to 250kHz, good for system integration
- Comprehensive protection functions: OVP/OCP/OPP/OTP, Sense protection
- Compatible with IT8700P mainframe, old and new modules can be matched
- Short-circuit peak current measurement function
- Available front/rear terminals*1
- 8 operating modes: CC/ CV/ CR/ CW/ CV+CC/ CR+
- CC/ CW+CC/ CV+CR (CR-LED)
- Automatic test function to tell whether the test results exceed the set specifications
- CV loop speed is adjustable to match different DUTs
- Multi channel synchronous control
*1 Current is limited to 15A using front terminals
Connectivity:
Documents and Software Solutions:
IT8700P+ series high-speed multi-channel DC electronic load is an upgraded version of the original IT8700P series with higher speed and higher precision. Its modules support master-slave paralleling connection for power extension.
It's compatible with IT8700P mainframe, the new modules and old modules can work together.
The IT8700P+ modules have faster dynamic response and can make the minimum rise time of current less than rising time of minimum current < 10 μs. In addition, the low internal resistance makes it suitable for low-voltage loading test. Faster loop speed can accurately control current without overshoot which improves test efficiency.
Furthermore, it has three current ranges for higher accuracy and lower ripple. The voltage and current measurement speed of this series has been upgraded to 250kHz.
The IT8700P mainframe has built-in LAN, USB and RS232 interfaces, and supports SCPI protocol. The IT8700P+ is suited for system integration as well as R&D and production line testing of a number of components and systems including super capacitors, fuel cells, lithium-ion batteries. High-speed AC-DC and DC-DC power supplies such as computer power supplies and communication power supplies.
