Keysight P5022B Streamline Series USB Vector network analyzer, 9 kHz to 9 GHz, 4 or 6-port

Key Features

  • 4- or 6-port, 9 kHz to 9 GHz
  • Add an optional second source on 4-port models (Option 402)
  • Improve throughput with fast Thunderbolt 3 interface
  • Choose from a wide range of measurement applications to gain deeper insight into your component tests
  • Share the portable VNA with other teams and locations
  • Extend the number of test ports by cascading two VNAs for multiport calibrated measurements
  • Measure with the same GUI, SCPI commands, and measurement science as Keysight’s trusted high-performance VNAs
  • Calibrate quickly with Keysight Electronic Calibration (ECal) modules
  • Upgrade your hardware with high performance-enabling software
  • Keep your instrument up-to-date with VNA activation software


Options for:

  • Basic Pulsed-RF measurements
  • Automatic fixture removal
  • Time domain analysis
  • Noise figure measurements with vector correction
  • Embedded LO capability
  • Gain compression measurements
  • Spectrum analysis
  • Multiport calibrated measurements

Documents and Software Solutions:

Product Number:

P5022B

Manufacturer:

Keysight Technologies

Quantity:

Total
Unit price
base price
Stock
Call or email for delivery time

The freedom of portable network analysis doesn’t have to mean a compromise in performance. The B-models of the Keysight Streamline Series VNAs unlock the full performance of the network analyzer hardware with fast measurements over Thunderbolt 3 connections to your host PC. Gain confidence in your measurements with best-in-class performance offering fast, reliable, and repeatable results. Explore the complete characterization of your devices with a rich portfolio of software applications that transform the compact network analyzer into a complete RF measurement solution.

The P50xxB series offers the performance required for testing passive components, amplifiers, mixers or frequency converters. The vector network analyzer (VNA) provides best-in-class key specifications such as dynamic range, measurement speed, trace noise and temperature stability. Choose from 2- or 4-port models up to 53 GHz, or 6-port models up to 20 GHz.

The P93xxB series provides excellent performance in general-purpose network analysis for passive components. With software applications like enhanced time domain analysis with TDR and automatic fixture removal, you can easily characterize passive components with the same performance of a benchtop setup. Choose from 2-port models up to 44 GHz or 4-port models up to 20 GHz.

The Streamline Series utilizes the same measurement science as other Keysight VNAs such as the PNA, ENA and PXI VNA. A common software platform makes it easy to choose the right level of performance to match budget and measurement needs. This commonality guarantees measurement consistency, repeatability, and a common remote-programming interface across multiple instruments in R&D and manufacturing.
