GW-INSTEK GPS-4303 200 W, 0-30 V, 2.2-5.2 V, 8-15 V, 4-Channel, Linear D.C. Power Supply

Key Features and Functions

  • 4 Independent Isolated Output
  • Four '3 Digits' LED Displays
  • 0.01% Load and Line Regulation
  • Low Ripple and Noise
  • Tracking Operation and Auto Series/Parallel Operation
  • Output ON/OFF Switch
  • Output Voltage and Current Setting When Output Disable
  • Fan Speed Control Circuit to Minimize Fan Noise
  • Over Load and Reverse Polarity Protection
  • Optional European Jack Type Terminal

Documents and Software Solutions:

Price

kr 4.692*
* excluding VAT plus shipping

Product Number:

GW-GPS-4303

Manufacturer:

GW-INSTEK

Quantity:

Total
Unit price
base price
Stock
Typically on stock
Quick Delivery

The GPS-Series is 2-4 channel, 180 to 200W output, linear DC power supplies. Overload and reverse polarity protection, and an output on/off switch keep the GPS-Series and their load safe from unexpected conditions. A High regulation (0.01%+3mV) and low ripple/noise (< 1mVrms, 5Hz~1MHz) are maintained for channel 1 and 2 in constant voltage mode. Automated cooling fan speed control minimizes fan noise according to load conditions, ensuring quiet operation. The GPS-Series is an ideal solution for lightweight, inexpensive bench-top or portable applications requiring high regulation and multiple outputs.

Channel Configuration:



GPS-4303

GPS-3303

GPS-2303



CH1

CH2

CH3

CH4

CH1

CH2

CH3

CH1

CH2

Voltage

0~30V

2.2~5.2V

8~15V

0~30V

5V Fixed

0~30V

Current

0~3A

1A Max.

1A Max.

0~3A

3A Max.

0~3A

Description
Additional Informations
Reviews
Query on the Item
Do you have any questions on this item?
Your E-mail Address
My Question:
Please retype the letters shown here
captcha
Description
Reviews
Query on the Item

The GPS-Series is 2-4 channel, 180 to 200W output, linear DC power supplies. Overload and reverse polarity protection, and an output on/off switch keep the GPS-Series and their load safe from unexpected conditions. A High regulation (0.01%+3mV) and low ripple/noise (< 1mVrms, 5Hz~1MHz) are maintained for channel 1 and 2 in constant voltage mode. Automated cooling fan speed control minimizes fan noise according to load conditions, ensuring quiet operation. The GPS-Series is an ideal solution for lightweight, inexpensive bench-top or portable applications requiring high regulation and multiple outputs.

Channel Configuration:



GPS-4303

GPS-3303

GPS-2303



CH1

CH2

CH3

CH4

CH1

CH2

CH3

CH1

CH2

Voltage

0~30V

2.2~5.2V

8~15V

0~30V

5V Fixed

0~30V

Current

0~3A

1A Max.

1A Max.

0~3A

3A Max.

0~3A
