Keysight LTS1R28U2 8100 Mobile Device Test System
Highlights
The 8100 5G Mobile Device Test System provides automated, scalable performance testing for 5G mobile devices across voice, data, video, and location technologies on a single expandable platform.
Test coverage and standards
- Supports frequency division duplex (FDD) and time division duplex (TDD) NR, FDD and TDD LTE (Option 3x), and standalone 5G (Option 2)
- Delivers 256 quadrature amplitude modulation (QAM) on both uplink and downlink with 4 downlink and 2 uplink multiple-input, multiple-output (MIMO) streams
- Provides standards-based conformance testing aligned to 3rd Generation Partnership Project (3GPP), Global Certification Forum (GCF), and PCS Type Certification Review Board (PTCRB) requirements
- Offers comprehensive assisted global navigation satellite system (A-GNSS) location testing across GPS, GLONASS, BeiDou, Galileo, Quasi-Zenith Satellite System (QZSS), and Navigation with Indian Constellation (NAVIC) constellations with multiple frequencies
Automation and analysis
- Runs fully automated tests with pre-configured, customizable test packs based on proven methodologies
- Includes user interface (UI)-based Development Library tools for rapid custom test creation, editing, and execution
- Provides integrated results reporting and analysis for device benchmarking and issue debug
Lab simulation and scalability
- Recreates real-world radio frequency (RF) conditions in the lab with integrated fading and additive white Gaussian noise (AWGN)
- Validates 5G devices on private networks with close-to-live network emulation - from RF environments to end-to-end application validation
- Scales from initial test needs to additional test areas on the same platform as requirements evolve
Keysight extends its industry-leading Global Navigation Satellite System (GNSS) expertise into the Over-the-Air (OTA) test environment with comprehensive standalone and assisted GNSS OTA test solutions. Powered by the OTA Test Pack option, the system fully automates all GNSS OTA test cases defined in the latest CTIA Test Plan, including A-GPS L1, A-GPS L1+L5, A-GPS L5, A-Galileo E1, A-Galileo E5a, and standalone GPS L1, GPS L5, Galileo E1, Galileo E5a, and GLONASS.
The system also supports China Communications Standards Association (CCSA) OTA test requirements for assisted and standalone BeiDou, GPS+BeiDou, BeiDou-only, and BeiDoupreferred operation, including signals B1i, B1c, B2a, B2i, B2b, and B3i. Keysight is the only solution certified to support the complete set of both CTIA and CCSA GNSS OTA test requirements. Customizable test parameters help optimize test time while enabling performance evaluation beyond the requirements of these industry standards.
OTA test capability is supported on Keysight’s 8100 Location Technology Solution (LTS) for GSM, UMTS, CDMA, LTE, and 5G NR devices. Due to its flexibility, the system can be configured to support testing of all devices in a single solution. The Keysight 8100 seamlessly integrates with the Keysight E7515B UXM 5G Network Emulator running RF Applications (RA) software. By combining the 8100 GNSS simulation capabilities with the UXM 5G signaling engine, this integrated solution enables automated cellular TRP/TIS and A-GNSS location testing over-the-air (OTA).
