| ZNL3-B1 Spectrum analysis function for ZNL3 (retrofittable in R&S service) |
| ZNL3-B22 Extended power range down to -40dBm, for ZNL (retrofittable in R&S service) |
| ZNL3-B31 Receiver step attenuator, port 1 electronical, 30 dB, 10 dB steps for ZNL3 (retrofittable in R&S service) |
| ZNL3-B32 Receiver step attenuator, port 2 electronical, 30 dB, 10 dB steps for ZNL3 (retrofittable in R&S service) |
| ZNL4-B1 Spectrum analysis function for ZNL4 (retrofittable in R&S service) |
| ZNL4-B22 Extended power range down to -40dBm, for ZNL4 (retrofittable in R&S service) |
| ZNL4-B31 Receiver step attenuator, port 1 electronical, 30 dB, 10 dB steps for ZNL4 (retrofittable in R&S service) |
| ZNL4-B32 Receiver step attenuator, port 2 electronical, 30 dB, 10 dB steps for ZNL4 (retrofittable in R&S service) |
| ZNL6-B1 Spectrum analysis function for ZNL6 (retrofittable in R&S service) |
| ZNL6-B22 Extended power range down to -40dBm, for ZNL6 (retrofittable in R&S service) |
| ZNL6-B31 Receiver step attenuator, port 1 electronical, 30 dB, 10 dB steps for ZNL6 (retrofittable in R&S service) |
| ZNL6-B32 Receiver step attenuator, port 2 electronical, 30 dB, 10 dB steps for ZNL6 (retrofittable in R&S service) |
| ZNL14-B1 Spectrum analysis function for ZNL14 (retrofittable in R&S service) |
| ZNL14-B22 Extended power range down to -40dBm, for ZNL14 (retrofittable in R&S service) |
| ZNL14-B31 Receiver step attenuator, port 1 electronical, 30 dB, 10 dB steps for ZNL14 (retrofittable in R&S service) |
| ZNL14-B32 Receiver step attenuator, port 2 electronical, 30 dB, 10 dB steps for ZNL14 (retrofittable in R&S service) |
| ZNL20-B1 Spectrum analysis function for ZNL20 (retrofittable in R&S service) |
| ZNL20-B22 Extended power range down to -40dBm, for ZNL20 (retrofittable in R&S service) |
| ZNL20-B31 Receiver step attenuator, port 1 electronical, 30 dB, 10 dB steps for ZNL20 (retrofittable in R&S service) |
| ZNL20-B32 Receiver step attenuator, port 2 electronical, 30 dB, 10 dB steps for ZNL20 (retrofittable in R&S service) |
| ZNZE1-B130 Configuration of 3.5mm(f)-compatible connector for port 1 of ZN-ZE1xx calibration units |
| ZNZE1-B131 Configuration of 3.5mm(m)-compatible connector for port 1 of ZN-ZE1xx calibration units |
| ZNZE1-B170 Configuration of N(f) connector for port 1 of ZN-ZE1xx calibration units |
| ZNZE1-B171 Configuration of N(m) connector for port 1 of ZN-ZE1xx calibration units |
| ZNZE1-B230 Configuration of 3.5mm(f)-compatible connector for port 2 of ZN-ZE1xx calibration units |
| ZNZE1-B231 Configuration of 3.5mm(m)-compatible connector for port 2 of ZN-ZE1xx calibration units |
| ZNZE1-B270 Configuration of N(f) connector for port 2 of ZN-ZE1xx calibration units |
| ZNZE1-B271 Configuration of N(m) connector for port 2 of ZN-ZE1xx calibration units |
| ZNL-B19 Additional removable solid state disk for ZNL, premounted on PC-board, including analyzer Firmware, for exchange against standard hard drive (hardware option) |
| ZNL-K14 Independent CW source for ZNL. Can be used as stimulus for the spectrum analysis. Requires option ZNLx-B1. (software license) |
| ZNL-K2 Time Domain Analysis for ZNL (software license) |
| ZNL-K3 Distance to Fault Measurements for ZNL |
| ZNL-U10 WIN10 2021 Upgrade Kit for ZNL and ZNLE (Hardware option) |
| ZNLE-B100 Extension of the lower end of the frequency range to 100 kHz |
| ZNH Vector Network Analyzer Software Options |
|---|
| ZNH-K10 DC Bias Variable Voltage Source (software license) |
| ZNH-K29 Pulse Measurements with Power Sensor (software license) |
| ZNH-K45 Vector voltmeter measurement application (software license) |
| ZNH-K47 Mixed Mode S-Parameters (software license) |
| ZNH-K66 Wave Ratio (software license) |
| ZNH-K68 Time Domain Analysis (software license) |
| ZNH-K69 Power Sensor Measurements Versus Frequency (software license) |
| ZNH-K9 Power Sensor Support (software license) |
| ZPH Cable Rider Software Options |
|---|
| ZPH-B10 GPS Support (software license) |
| ZPH-B22 Spectrum Analyzer Preamplifier (required ZPH-K1) (software license) |
| ZPH-B4 Cable and Antenna Analyzer Frequency Upgrade, 3 GHz to 4 GHz (software license) |
| ZPH-K1 Spectrum analysis measurement application (software license) |
| ZPH-K15 Interference Analysis (required ZPH-K1) (software license) |
| ZPH-K16 Signal Strength Mapping Measurement Application (required ZPH-K1) (software license) |
| ZPH-K19 Channel Power Meter (software license) |
| ZPH-K29 Pulse Measurements with Power Sensor (software license) |
| ZPH-K57 Advanced Gated Trigger, ACLR, OBW, Spectrum Emission Mask (SEM) (software license) |
| ZPH-K7 Modulation Analysis - AM/FM (required ZPH-K1) (software license) |
| ZPH-K9 Power Sensor Support (software license) |
| ZVH Handheld cable and antenna analyzer |
|---|
| ZVH-K1 Spectrum analysis measurement, application (software license) |
| ZVH-K14 Spectrogram measurement, application requires ZVH-K1) (software license) |
| ZVH-K19 Channel power meter (software license) |
| ZVH-K29 Pulse Measurements with Power Sensor (software license) |
| ZVH-K39 Transmission measurement, application (software license) |
| ZVH-K40 Remote control via USB or LAN, application (software license) |
| ZVH-K42 Vector network analysis, application (software license) |
| ZVH-K45 Vector voltmeter measurement, application (software license) |
| ZVH-K9 Power meter application. FSH or NRP-power sensors required (software license) |
